| 型号 Model | Unit | CPCD30 | ||
| 动力形式Power type | 内燃 Diesel | |||
| 额定起重量Rated capacity | kg | 3000 | ||
| 载荷中心距Load center | mm | 500 | ||
| 标准起升高度Lift height | mm | 3300 | ||
| 门架倾角(前/后)Mast tilt angle (forward/backward) | Deg | 10/12 | ||
| 轴距 Wheel-base | mm | 1850 | ||
| 轮距（前/后）Tread(front/rear) | mm | 1350/1290 | ||
| 行车制动 Travel brake | 液压-踏板式Hydraulic-Foot pedal | |||
| 停车制动 Parking brake | 机械-手动式Mechanical-Hand lever | |||
| 起升速度（满载）Lift speed(with load) | mm/s | 380/520 | ||
| 下降速度（满载/空载）Lower speed (with/without load) | mm/s | 满载(with load)＜600 ，空载(without load)＞300 | ||
| 行驶速度（空载）Travel speed (without load) | km/h | 20/25 | ||
| 最大爬坡（满载）Max. gradeability (with load) | % | 20 | ||
| 发动机 Engine | 型号 Model | A498BPG | ||
| 制造商 Manufacturer | 新昌Xinchang | |||
| 额定功率 Rated power | kw | 45/2500 | ||
| 最大扭矩 Max. rotation | Nm/rpm | 193/1800 | ||
| 排量Displacement | L | 3.168 | ||
| 蓄电池 Battery | 电压 Voltage | V | 12 | |
| 容量 Capacity | Ah | 100 | ||
| 变速箱 Gearbox | 传动形式Transmission type | 液力 Hydraulic | ||
| 档位（前/后）Gears,speed (front/rear) | Ⅰ/Ⅰ | |||
| 轮胎 Tire | 类型 type | 充气胎 Pneumatic tyre | ||
| 型号 Model | 前 front | 14-17.5-14PR | ||
| 后 Rear | 10-16.5-10PR | |||
| 自重Self.weight | kg | 4600 | ||
| 自由起升高度Free lift height | mm | 120 | ||
| 货叉Fork | 厚度×宽度×长度Thickness×Width×Length | mm | 40×125×1070 | |
|
外形尺寸 Overall dimensions |
全长（不带货叉）Overall length(without forks) | mm | 2930 | |
| 全宽Overall width | mm | 1800 | ||
|
全高 Overall height |
门架升起时Extended height(mast) | mm | 4650 | |
| 门架未升起Lower height(mast) | mm | 2342 | ||
| 护顶架Overhead guard | mm | 2452 | ||
| 最小转弯半径Min. turning radius | mm | 3050 | ||
|
最小离地间隙 Min. under ground clearance |
门架处 Under mast | mm | 220 | |
| 轴距中点处Center of wheel-base | mm | 315 | ||
